1. Key Features:

• The JTC-7215 air impact wrench features an ultra-compact design, measuring only 138 mm in length, making it ideal for working in tight spaces.
• Lightweight at only 1.8 kg, reducing fatigue during prolonged use.
• Equipped with a Jumbo Hammer mechanism for powerful performance and long-lasting durability.
• Free speed of up to 9000 rpm ensures fast and efficient operation.
• Maximum torque of 1500 ft/lb (2034 Nm) is suitable for large bolts and nuts.

2. Specifications:

• Free speed: 9000 rpm.
• Bolt capacity: 1-5/8".
• Air inlet: 1/4".
• Air pressure: 90-120 psi.
• Maximum torque: 1500 ft/lb (2034 Nm).
• Weight: 1.8 kg.
• Length: 138 mm.
• Mechanism: Jumbo Hammer.

3. Practical Applications:

• Used for tightening and loosening bolts and nuts in automotive repair, truck maintenance, and mechanical equipment.
• Suitable for professional repair shops and individuals requiring a compact, efficient tool.
• Applicable in heavy industries that demand high torque and quick operation.

4. How to Use:

• Connect the impact wrench to an air compressor using a 1/4" air inlet.
• Adjust the air pressure to 90-120 psi for optimal performance.
• Select the appropriate socket size for the bolt or nut being tightened or loosened.
• Operate the tool by pulling the trigger and adjusting the force as needed.
• After use, clean and store the tool in a dry place to ensure durability.
