h2MIG/MAG WELDER DECA D-MIG 520SD
Price: Call
Share
|
|
|
Mr. Vui
0944755799
| | |
Mr. Định
0968776499
| | |
Mr. Thuyên
0963829640
| | |
Nhân Võ Đình (HCM)
0967161443
| | |
Lê Thị Thanh Hương
0979898586
Description
· Code: 259000 power source with torch euro connector and 180A torch, L = 3mMIG MAG wire feed welder - Simple Weld Series
· self adijusting Wire Speed System
· Equipped with SIMPLE WELDdigital synergic technology
· For mild steel solid wire or mig braze-wire Cu Si3 / Cu Al (to weld HSS, EHS, UHS and BORO STEEL), aluminium Mg / Si.
Features
| Welding current range (Amp): | 30 - 180A |
| Welding positions (N°): | 6 |
| Duty Cycle (Amp) (EN 60974-1 40°C): | (140A - 15%) - (75A - 60%) |
| Open circuit voltage (Volt): | 28 - 53V |
| Wire Suitable Spool: | Ø mm 200 - 300 |
| Steel wire (Ø mm): | Ø 0,6 - 0,8 - 1,0 mm |
| Stainless steel wire (Ø mm): | Ø 0,8 - 1,0 mm |
| Aluminiumn Mg - Si wire (Ø mm): | Ø 0,8 - 1,0 mm |
| CuSi Wire (Ø mm): | Ø 0,8 - 1,0 mm |
| Alimentation volt (50/60 Hz): | 1 Ph x 230V |
| Installation Power (Kw): | 2 KW - 60% |
| Fuse (Amp): | 16A |
| Wire feeder: | 2 rulli - 2 rollers |
| Torch connection: | euro |
| Socket: | 25 mm2 |
| Weight kg ≅: | 47.5 |
| Dimensions (mm): | 505 x 840 x 765 |
| FEATURES: | : |
| Synergic / Simple Weld: | yes |
| Brazing: | yes |
| Spot: | yes |
| Soft Start: | yes |
| 2T - 4T: | yes |
| Stitch: | yes |
| Burn back: | yes |
| Ammeter / Voltmeter: | yes |
| Thermostatic Protection: | yes |
| LOGISTIC INFO CODE: | 259000 |
| Barcode: | 8011399023824 |
| Package dimension, Wid.-Dep.-Height (mm): | 800 x 395 x 600 |
| Package weight kg: | 52 |
| Pieces for pallet: | 6 |
| HS code: | 85153100 |
