Nitto 20 SM Air Quick Coupler

Nitto 20 SM Air Quick Coupler
Air flows in either direction from plug or from socket side when coupled.
Ideal for connection of factory air supply lines to pneumatic devices.

-Can be connected with plugs for Hi Cupla Models 10, 17, 20, 30 and 40 and allows fluid to flow from either plug or socket side when coupled.
-Wide range of connections such as from ports on air pipes in factory to  individual pneumatic devices.
-Critical structural parts are heat-treated for increased strength giving greater durability and resistance to wear.
-Available in various sizes and end configurations to suit a wide range of applications.

Specification
Series Name: Hi Cupla TW Type
Applicable Fluid: Air
Shape: Socket (Female)
Body Material: Steel
Seal Material: Nitrile rubber
Valve Structure: with valve
Characteristic: For bidirectional compressed
Working Pressure: 0 ～ 1.5 MPa
End Configuration: Male thread
Size of End Configuration: 1/4
Working Temperature: -20 ～ 80 ℃
