Wireless Weigh Pad - Portable Axle Scale Top Sensor Tech TS-07T
1. Key Features
- Ultra-thin design with durable aluminum alloy/steel alloy material.
- High load capacity (10-20 tons per pad, up to 40 tons per axle).
- High accuracy in both dynamic weighing (2-5%) and static weighing (0.5-1%).
- IP67 water resistance, suitable for harsh environments.
- Integrated touch screen and printer for clear result display.
- Wireless 2.4G signal transmission with a range of 20-30m.
- Large storage capacity, saving over 2000 test results.
2. Technical Specifications
- Model: TS-07T
- Brand: TOP SENSOR TECH
- Origin: China
- Weigh Pad Dimensions: 800x400x22.5mm
- Load Capacity: 10-20 tons per pad, up to 40 tons per axle.
- Test Speed: Maximum 5km/h.
- Power Supply: 6V DC, built-in rechargeable AAA battery, continuous operation for 20 hours.
- Weigh Pad Weight: 23kg, portable.
- Operating Temperature: -10℃ to 60℃.
- Accuracy:
- Dynamic: 2-5%.
- Static: 0.5-1%.
- Water Resistance: IP67.
- Result Display: Tire weight, axle weight, speed, overload status, etc.
- Communication Protocol: RS232 or 485.
3. Real-World Applications
- Vehicle weight checks at mobile or fixed weighing stations.
- Transportation industry for vehicle load monitoring and control.
- Factories and warehouses for weighing cargo vehicles.
- Axle load checks in the construction and heavy industry sectors.
4. How to Use
- Preparation:
+ Place the weigh pads on a flat, clean surface.
+ Check the battery and ensure the weigh pads are operational.
- Connection:
+ Turn on the weigh pads and the control display.
+ Establish a wireless signal connection between the pads and the display unit.
- Weighing Process:
+ Drive the vehicle over the weigh pads at a speed not exceeding 5km/h.
+ Stop the vehicle for static weighing to achieve the highest accuracy.
- Display and Print Results:
+ The weighing results (tire weight, axle weight, overload status) will appear on the touch screen.
+ Print the results if needed for record-keeping or reporting.
- Saving Results:
+ Use the integrated memory to store over 2000 test results.
- Maintenance:
+ Clean the weigh pads and store them in a dry place after use.
+ Recharge the batteries as needed.
