Chint NXC-18 Contactor 3-Pole 18A

1. Key Features

• Chint NXC-18 contactor complies with IEC 60947 standards.

• Rated current 18A, motor control capacity 7.5kW.

• Equipped with 1NO + 1NC auxiliary contact.

• Operating voltage 690VAC, coil options available (220V, 380V,...).

• Withstands impulse voltage up to 8kV.

• High mechanical durability up to 1.2 million operations.

• Compatible with thermal relay NXR-25 for motor protection.

2. Technical Specifications

• Model: NXC-18

• Poles: 3P

• Rated current: 18A

• Power capacity: 7.5kW

• Auxiliary contacts: 1NO + 1NC

• Coil voltage: 220V, 380V,...

• Operating voltage: 690VAC

• Impulse withstand voltage: 8kV

• Mechanical endurance: 1.2 million operations

• Standard: IEC 60947

• Thermal relay compatibility: NXR-25

• Brand: CHINT

3. Applications

• Motor control and protection for medium and small power motors.

• Used in industrial panels, motor control systems.

• Applied in pumps, fans, compressors, HVAC systems.

• Suitable for production lines, factories, industrial zones.

4. How to Use

• Install in electrical panels or cabinets, fixed with screws or DIN rail.

• Connect wiring according to the diagram, tighten terminals securely.

• Select coil voltage according to system requirements (220V or 380V).

• Combine with NXR-25 thermal relay for motor protection.

• Regular inspection and maintenance recommended.
